SKU: 460623 | Brand: Panasonic | Condition: New
✔ In Stock
Power Supply: | DC7.2V (using battery), 7.3V (using AC adaptor) |
Power Consumption: | 11.6W (when recording) |
Operating Temperature: | 0°C to 40°C |
Operating Humidity: | 10% to 80% (no condensation) |
Weight: | Approx. 2.4 kg (camcorder main body only) |
Dimensions (WxHxD): | 180 mm x 195 mm x 438 mm, excluding the projection part |
Pick-up Device: | 1/3 Type Progressive, 2.2Mil Pixels, 3MOS |
Number of Effective Pixels (HxV): | 1920 x 1080 |
Lens: | Panasonic lens with optical image stabilizer, motorized/manual mode switching, 22x zoom, F1.6 - 3.2 (f=3.9mm to 86mm / 35mm equivalent: 28 mm to 616 mm, 16:9) |
Filter Diameter: | 72 mm |
Optical Color Separation: | Prism system |
ND Filter: | OFF, 1/4, 1/16, 1/64 |
Minimum shooting distance: | Approx. 1 meter |
Gain Selection: | 0 / +3 / +6 / +9 / +12 / +15 / +18 / +24 / +30 dB (+24 & +30 dB are to be allocated only for USER SW) |
Color Temperature settings: | ATW, ATW LOCK, Preset 3200K, Preset 5600K, Preset VAR, Ach, Bch |
Digital Zoom: | 2x / 5x / 10x (to be allocated on USER button, switching by pushing the button) |
Minimum Luminance: | 0.4 lx (when F1.6, +30dB of gain, and 1/30 sec. of shutter speed) |
Shutter Speed (Preset): | 60i/60p mode: 1/60 sec(OFF). 1/100 sec., 1/120 sec., 1/250 sec., 1/500 sec., 1/1000 sec., 1/2000 sec. 30p mode: 1/30 sec, 1/50 sec(OFF)., 1/60 sec., 1/120 sec., 1/250 sec., 1/500 sec., 1/1000 sec., 1/2000 sec. 24p mode: 1/24 sec., 1/50 sec(OFF)., 1/60 sec., 1/120 sec., 1/250 sec., 1/500 sec., 1/1000 sec., 1/2000 sec. |
Shutter Speed (Synchro Scan): | SYNC SCAN TYPE = sec. 60i/60p mode: 1/60.0 sec. to 1/249.8 sec. 30p mode: 1/30.0 sec. to 1/249.8 sec. 24p mode: 1/24.0 sec. to 1/249.8 sec. SYNC SCAN TYPE = deg. All mode: 3.0 deg. to 360.0 deg. (by 0.5 degree step selectable) (default = 180.0 deg.) |
Slow Shutter Speed: | 60i/60p mode: 1/8 sec., 1/15 sec. and 1/30 sec. 30p mode: 1/8 sec. and 1/15 sec. 24p mode: 1/6 sec. and 1/12 sec. |
RECORDING FORMAT - AVCHD: | . |
Compression Method: | MPEG-4 AVC/H.264 |
Recording Media: | SD Memory Card: 512MB, 1GB, 2GB (FAT12, FAT16) SDHC Memory Card: 4GB, 6GB, 8GB, 12GB, 16GB, 32GB (FAT32) SDXC Memory Card: 48GB, 64GB, up to 2TB (exFAT) *PH/HA mode requires Class4 or faster Card. VFR recording requires Class6 or faster. |
Recording Video Format: | PH mode: 1080/59.94i, 1080/29.97p (over 59.94i), 1080/23.98p, 720/59.94p, 720/29.97p (over 59.94p), and 720/23.98p HA, HE mode: 1080/59.94i only PM mode: 720/59.94p |
Transmission Rate: | PH mode: Approx. 21 Mbps (VBR, max 24 Mbps) PM mode: Approx. 8 Mbps (VBR) HA mode: Approx. 17 Mbps (VBR) HE mode: Approx. 6 Mbps (VBR) |
Interval Recording: | OFF / 1 sec. / 10 sec. / 30 sec. / 1 min. / 2 min. *Recording mode need to be set in "PH 1080/30p" or "1080/23.98p". Maximum continuous recording dyration is 168 hours (7 days). |
Recording Format: | DV |
File Format: | AVI Type2 |
Recording Media Format: | SD Memory Card: 512MB, 1GB, 2GB (FAT12, FAT16) SDHC Memory Card: 4GB, 8GB, 16GB, 32GB (FAT32) SDXC Memory Card: 48GB, 64GB, up to 2TB (exFAT) *DV recording requires Class6 or faster. |
SDI OUT - Video (AVCHD): | No SDI OUT |
HDMI OUT - Video (AVCHD): | HDMI x 1, Type A (1080i / 720p) |
VIDEO OUT - Video (AVCHD): | Pin jack × 1, 1.0Vp-p, 75 ?, 480/60i |
VIDEO OUT - DV: | . |
SDI OUT - Video (DV): | No SDI OUT |
VIDEO OUT - Video (DV): | Pin jack × 1, 1.0Vp-p, 75 ?, 480/60i |
AUDIO RECORDING - AVCHD: | . |
AUDIO RECORDING - AVCHD Compression: | Dolby Digital/2ch |
AUDIO RECORDING - AVCHD Sampling Frequency: | 48k Hz |
AUDIO RECORDING - AVCHD Quantization: | 16 bit |
Bit Rate: | PH mode: 384kbps PM/HA/HE mode: 256kbps |
AUDIO RECORDING: | DV |
Sampling Frequency: | 48k Hz |
Quantization:: | 16 bit |
Built-in Microphone: | Stereo microphone |
Audio IN: | XLR (3 pins) × 2 (INPUT 1, INPUT 2) LINE / MIC switchable, high-impedance LINE: 0 dBu MIC: -40 / -50 / -60 dBu (selectable in menu MIC POWER: +48V ON/OFF switchable |
Audio IN Additional information: | Headroom 12dB |
Audio Out: | Pin jack × 2 (CH1, CH2), Output: 316 mV, 600 ? |
SDI OUT - Audio (AVCHD): | No SDI OUT |
HDMI OUT - Audio (AVCHD): | 2 ch (Linear PCM) 5.1ch (Dolby Digital) |
Headphone: | Stereo mini jack (3.5 mm diameter) × 1 |
Built-in Speaker: | 20 mm (round) × 1 |
Camera Remote: | Super Mini jack (2.5mm diameter) x 1 for ZOOM and recording START/STOP operations Mini jack (3.5mm diameter) x 1 for FOCUS and IRIS controls |
INDEX Remote: | Super Mini jack (2.5 mm diameter) x 1 |
TC PRESET IN/OUT (double as VIDEO OUT): | IN: 1.0 to 4.0 Vp-p, 10 k? OUT: 2.0±0.5 Vp-p, low impedance |
USB2.0: | Type mini B connector (compliant with USB ver. 2.0) |
DV OUT (only for DV mode): | IEEE 1394 6pin x 1 |
LCD Monitor: | 3.45 inches, LCD color monitor, approx. 921,000 pixels (16:9) |
Viewfinder: | 0.45 inches, LCD color viewfinder, approx. 1,226,000 pixels (16:9) |
Accessories (attached to the unit): | Lens Cap, INPUT Terminal Cap x2, Lens Hood, Hand Strap |
